Smart Bluetooth Glasses with Directional Open Ear Audio & ENC Noise Canceling Microphones | Square Transparent Frame Wireless Audio Sunglasses

OEM/ODM Wireless Audio Smart Sunglasses: Open-Ear Bluetooth 5.3 Eyeglasses with Beamforming HD Call & UV Protection for Wholesale

📄 Technical Specification Datasheet (PDF)

Includes complete PCB layout, battery safety, & optical parameters.

Download PDF

Your Name *

Work Email *

Company Name *

Estimated Quantity *

Custom Requirements / Questions

Technical Specifications

OEM / ODM Customization

Package & Quality Standards

Premium Audio & Privacy Protection: Features Open Sound State technology with directional sound transmission to minimize sound leakage, delivering deep bass and balanced high/mid frequencies without blocking ambient noise.
Crystal-Clear HD Calling: Powered by the JL7016 Chipset with Stereo ENC Noise Cancellation and Beamforming Microphones (-42±3dB) for crystal-clear hands-free calls even in noisy environments.
Durable Integrated Frame & Aesthetic Design: Built with an integrated injection molding transparent frame, heavy-duty metal hinges for smooth folding, and anti-UV lenses for complete optical protection.
Intuitive Auto Power & Touch Control: Smart temple sensor automatically turns on/connects when opened and powers off/disconnects when folded. Responsive touch controls on both left and right temples.
Long Battery Life & Fast Charging: Enjoy up to 6 hours of continuous playback (at 80% volume) with quick Type-C charging (< 2 hours).
Technical Specifications Table

Parameter / Feature	Value / Details
Model / Chipset	JL7016 Stereo ENC Noise Cancellation
Bluetooth / Reception Distance	$ge$ 10 Meters
Operating Frequency	2.402 GHz – 2.480 GHz
Transmission Power	CLASS 2, MAX 4dBm
Signal-to-Noise Ratio (SNR)	-89dBv
Distortion Rate	< 1%
Frequency Response	20Hz – 20KHz
Speaker Type & Spec	0925 Speaker Unit
Speaker Impedance & Power	$16pm15%Omega$, Rated Power: 1W
Microphone Sensitivity	-42$pm$3dB (Beamforming ENC Mic)
Battery Life & Playback	~6 Hours (at 80% volume)
Charging Time & Port	$le$ 2 Hours (Type-C Fast Charging)
Standby / Operating Current	Standby: $le 5mu ext{A}$ \| Operating: $$le 30 ext{mA$
Frame Dimensions	Width: 150mm \| Height: 50mm \| Temple Length: 155mm
Frame Material & Structure	Integrated Injection Molding, Metal Hinge, Transparent Aesthetics
Color Options	Amber (琥珀色), Moonlit White (月光白), Tea Brown (茶棕色)
Lens Function	UV Protection (Filters harmful ultraviolet rays)

Touch-Sensitive Controls Setup

Left / Right Temple Universal Touch Controls:

Single Tap: Left: Volume Up / Right: Play & Pause
Double Tap: Left: Volume Down & Answer/End Call / Right: Next Track & Answer/End Call
Triple Tap: Right: Previous Track
Press and Hold (2s): Microphone On / Off
Press and Hold (5s): Force Shutdown / Power On
Single Tap + Press and Hold (5s): Connect to New Bluetooth Device
Double Tap + Press and Hold (5s): Factory Reset

B2B Service Section

OEM / ODM Customization Available: Custom Logo printing on frame/temples, customized packaging box, and custom lens options (Polarized / Blue-light blocking / Prescription compatible).
Sample Policy: Sample orders available for quality testing and sound performance review before bulk orders.
Factory Direct Supply: Stable lead times, strict quality control (QC), and competitive tiered pricing for wholesale buyers.

Silk-screen or laser engraving of your brand logo on the temples, custom frame colors, and custom sunglass/optical lens options.

Custom Bluetooth pairing name, localized voice assistant prompts, and complete Android/iOS SDK for proprietary app development.

Full-color custom gift box packaging, branded protective eyewear case, cleaning cloth, and multi-language user manuals.

Inspection Standard: 100% AQL Level II sampling before packing.
Drop & Sweat Testing: Passes 1.2m drop test and anti-sweat corrosion standards (IP54 rated).
Carton Packaging: 20 Units / Master Outer Carton, double-walled reinforced export box with anti-static foam lining.
Battery Safety Compliance: Full UN38.3 and MSDS certification for global air & sea freight.
